Ricoh TH5241
Key Features
| Print Width | 1.06 in (27.1 mm) |
|---|---|
| Resolution | Up to 1,200 dpi |
| Drop Size | 3pl (Single) / 3–12pl (Up to 21pl Multi-drop) |
| Viscosity | 7mPa·s |
| Temperature Range | Up to 40°C |
Applications
-
Wide Format Graphics
-
Labels
-
Textiles
-
Direct-to-Garment (DTG)
-
Industrial Printing
-
Direct to Object (DTO)
Differentiators
-
Thin-film piezo MEMS technology for superior print quality
-
High-resolution printing up to 1,200 dpi
-
Compact printhead design for easier system integration
-
Compatible with UV, Solvent, and Aqueous inks
-
Multi-drop technology for smooth grayscale printing
-
Supports up to four ink colors
-
Stable jetting performance for reliable production
Additional Information
High-Resolution MEMS Printhead
The Ricoh TH5241 utilizes Ricoh's proprietary thin-film piezo silicon MEMS technology to deliver exceptional image quality in a compact footprint. With 1,280 nozzles arranged across four rows, the printhead produces crisp, high-definition output at resolutions up to 1,200 dpi, making it suitable for demanding industrial printing applications.
Advanced Grayscale Printing
The integrated multi-drop technology combines multiple droplets before they reach the substrate, enabling variable drop sizes from 3 pl to 21 pl. This capability delivers smoother gradients, improved grayscale reproduction, and enhanced image quality across a variety of print applications.
Broad Ink Compatibility
Designed for maximum flexibility, the TH5241 supports UV-curable, solvent, and aqueous inks. This wide compatibility allows OEMs and printer manufacturers to deploy a single printhead platform across multiple industrial markets and printing technologies.
Compact Design for Easy Integration
With overall dimensions of only 52.7 × 45.8 × 55.4 mm and a lightweight 63 g construction, the TH5241 simplifies printer design while maintaining robust industrial performance. Its compact footprint makes it ideal for space-constrained print systems.
Reliable Industrial Performance
Engineered for continuous industrial operation, the TH5241 features integrated temperature sensing, supports firing frequencies up to 40 kHz, and provides stable droplet formation across a wide range of production environments, ensuring consistent print quality and long-term reliability.
